Self-Sealing Oil Suction Filter (External Tank For Hydraulic System Protection)

Structural & Operational Convenience

Self-Sealing Design for Easy Maintenance: The built-in self-sealing valve automatically closes when opening the filter cover, isolating the oil path to avoid oil spillage-simplifying filter element cleaning/replacement for Hydraulic System Protection.

Flexible Tank-Mounted Installation: Can be directly installed on the side, top, or bottom of oil tanks; the filter head is exposed outside the tank, and the suction cylinder immerses below the oil level, fitting diverse Tank-Mounted Filtration spatial layouts.

Simplified Piping System: Equipped with tubular/flange connections and built-in self-sealing valves, eliminating the need for additional stop valves and simplifying pipeline assembly in hydraulic systems.

Performance & Reliability

Low Pressure Loss & High Flow Capacity: Features original pressure loss <0.01MPa and rated flow from 25–800L/min, ensuring unobstructed oil suction in Tank-Mounted Filtration while maintaining filtration efficiency.

Intelligent Protection for Hydraulic Systems: Equipped with a pollution transmitter (triggers at 0.018MPa outlet vacuum) and oil bypass valve (opens at 0.02MPa vacuum), preventing oil pump suction failure and enhancing Hydraulic System Protection reliability.



Company Overview  Henan Hengyuan Technology Co., Ltd. is situated in Nanpu Juren Road, Changyuan City, Henan Province. It boasts modern technical equipment and robust economic strength.
