Introduction
In recent years, the issue of air pollution has gained significant attention worldwide. One of the primary solutions to combat this problem is the use of high efficiency air filters. These filters are designed to remove pollutants and allergens from the air, ensuring cleaner and healthier indoor environments.
There are several types of high efficiency air filters available in the market, each with its unique features and benefits. One of the most popular types is the pleated filter, which is made of multiple layers of synthetic material folded together to form a dense and efficient filtering matrix. Pleated filters are known for their high dust holding capacity and effectiveness in capturing particles as small as0.3 micrometers.
Another type of high efficiency air filter is the electrostatic filter. These filters use static electricity to attract and capture pollutants in the air. Electrostatic filters are often used in industrial settings and are known for their ability to handle high volumes of air and particle loads.
Main Feature
●High efficiency and thin thickness.
●Convenient installation and low operating cost.
●Suitable for terminal filtration of air conditioning units and purification environments with high coverage of high-efficiency filters.
Model, size and technical parameters
|
Filter model |
Overall dimensions (mm) |
Rated air flow (m3/h) |
Initial resistance (Pa) |
Efficiency (@ 0.3μm) |
Dust capacity(g) |
|
HWB-3.5B |
305X610X50mm |
350m3/h |
≤220Pa |
≥99.99 |
220 |
|
HWB-7B |
610X610X50mm |
700m3/h |
450 |
||
|
HWB-5B |
305X610X69mm |
500m3/h |
300 |
||
|
HWB-10B |
610X610X69mm |
1000m3/h |
600 |
||
|
HWB-15B |
915X610X69mm |
1500m3/h |
900 |
||
|
HWB-18B |
1170X570X69mm |
1800m3/h |
1100 |
||
|
HWB-20B |
1220X610X69mm |
2000m3/h |
1200 |
||
|
HWB-4.5B |
350X350X80mm |
4500m3/h |
250 |
||
|
HWB-5B |
400X400X80mm |
500m3/h |
300 |
||
|
HWB-8B |
484X484X80mm |
800m3/h |
450 |
||
|
HWB-10B |
550X550X80mm |
1000m7h |
600 |
||
|
HWB-13.5B |
610X610X80mm |
1350m3/h |
750 |
||
|
HWB-15B |
630X630X80mm |
1500m3/h |
800 |
||
|
HWB-20B |
915X610X80mm |
2000m3/h |
1100 |
||
|
HWB-27B |
1220X610X80mm |
2700m7h |
1500 |
||
|
HWB-9B |
484X484X90mm |
900m3/h |
550 |
||
|
HWB-14.5B |
610X610X90mm |
1450m3/h |
850 |
||
|
HWB-29B |
1220X610X90mm |
2900m3/h |
1700 |
Note:High Efficiency Air Filter Without Partition According to user requirements, different specifications and models of filters can be customized.
