Self-Sealing Magnetic Return Line Filter (Magnetic Filtration For Hydraulic System Return Oil)

Filtration Performance & Contamination Control

Magnetic Filtration Precision: The permanent magnet enables Magnetic Filtration of ferrous particles above 1μm, complementing fine filtration to remove wear-generated metal debris in Hydraulic Return Oil Purification.

Flow Diffusion & Anti-Contamination: The liquid diffuser ensures smooth oil return to the tank (reducing air entrainment and pollutant turbulence), while the pollution accumulation cup prevents contaminant re-entry during filter element replacement-critical for Tank-Side Hydraulic Filtration reliability.

Installation & System Protection

Multi-Position Mounting Flexibility: Supports Multi-Position Mounting (tank top/side/bottom) with flange connections, simplifying pipeline layout for Tank-Side Hydraulic Filtration and general hydraulic systems.

Self-Sealing & Bypass Safety: The self-sealing check valve prevents oil leakage during maintenance, and the bypass valve (opens at 0.4MPa differential pressure) protects the filter and system during cold starts or clogging-enhancing stability for Hydraulic Return Oil Purification.

Intelligent Monitoring: Visual/electrical alarm (triggers at 0.35MPa) provides real-time clogging feedback, enabling timely filter element replacement for uninterrupted Tank-Side Hydraulic Filtration.
