Product Description: Air Purification System Waste Incineration PTFE Dust Collector Bag Filter
Core Features and Advantages
High-Efficiency Filtration Performance
Material: Made of 100% PTFE (Polytetrafluoroethylene) base fabric with a PTFE membrane layer, ensuring filtration precision and stability.
Filtration Efficiency: ≥99.995% retention rate for particulates ≥0.1 microns, with a dynamic dust removal rate of 99.995% and a static dust removal rate of 99.999%, meeting waste incineration flue gas emission standards (EU 2000 standard ≤10 mg/m³).
Air Permeability: Air permeability of 20–45 L/(m²·s) @200Pa, balancing filtration efficiency and pressure drop to reduce system energy consumption.
High-Temperature and Corrosion Resistance
Continuous Operating Temperature: 250°C (some models up to 260°C), with an instantaneous peak temperature of 280°C, suitable for high-temperature flue gas from incinerators.
Chemical Stability: Resistant to strong acids, alkalis, and organic solvents, making it ideal for purifying flue gas containing corrosive gases such as HCl, HF, and SO₂.
Sealed Back Panel and Structural Optimization
Double-Layer Lockstitch Seaming: Utilizes an advanced international double-layer interlocking stitching structure to prevent unraveling and deformation, extending filter bag lifespan.
Sealed Design: Equipped with stainless steel elastic bands at the bag opening for a tight fit with the tube sheet, preventing air leakage and ensuring filtration efficiency.
Durability and Maintenance Cost
Service Life: ≥4 years (24-hour daily operation), significantly longer than the 1–2 years of standard filter bags.
Low Failure Rate: <1% failure rate in the first 3 years and <5% in the 5th year, reducing replacement frequency and downtime losses.
Hydrolysis Resistance: While hydrolysis resistance is moderate, it is partially compensated by membrane coating, making it suitable for dry or semi-dry flue gas conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Material | 100% PTFE fiber + PTFE membrane |
| Weight | 800–850 g/m² |
| Thickness | 1.2 ± 0.1 mm |
| Longitudinal Tensile Strength | ≥850 N |
| Transverse Tensile Strength | ≥800 N |
| Longitudinal Elongation | ≤35% |
| Transverse Elongation | ≤25% |
| Operating Resistance | ≤1200 Pa (design air velocity ≤0.8 m/min) |
| Surface Treatment | Membrane coating, heat setting, antistatic treatment |
Application Scenarios
Waste Incineration Power Plants
Captures fly ash, dioxins, and heavy metals in incineration flue gas, achieving ultra-low emissions when paired with activated carbon injection systems.
Adapts to high-humidity, highly corrosive flue gas environments, reducing filter bag damage risks.
Industrial Hazardous Waste Treatment
Filters flue gas containing toxic gases (e.g., mercury, cadmium compounds) to prevent secondary pollution.
High-temperature resistance meets the demands of rotary kiln incinerators.
Cement/Steel Industry
Replaces traditional fiberglass filter bags, extending service life and reducing maintenance costs.
Suitable for high dust concentration conditions (inlet dust ≤1000 g/Nm³).
Improvements Over Standard Filter Bags
| Metric | PTFE Membrane Filter Bag | Standard Filter Bag (Fiberglass/Polyester) |
|---|---|---|
| Filtration Efficiency | ≥99.995% | 90%–95% |
| Temperature Resistance | 250°C continuous | 150–180°C |
| Corrosion Resistance | Strong acids, alkalis, organic solvents | Weak acids/alkalis only |
| Service Life | ≥4 years | 1–2 years |
| Failure Rate | <1% (first 3 years) | 5%–10% annually |
Recommendation
If you manage waste incineration, hazardous waste treatment, or high-temperature industrial dust removal projects and aim for:
Ultra-Low Emissions: Meeting stringent EU or domestic environmental standards (dust ≤10 mg/m³).
Long-Term Stability: Reducing filter bag replacement frequency and lowering lifecycle costs.
Harsh Condition Adaptability: Withstanding high temperatures, corrosion, and condensation to avoid frequent shutdowns.
This PTFE membrane filter bag is the ideal choice. Its sealed design, high-efficiency filtration, and durability significantly enhance system reliability, particularly in high-capacity, high-emission-requirement scenarios.
