RF Series Direct Return Line Filter Hydraulic Oil Return Filter For Hydraulic Station

1. Product Introduction

RF Series Direct Back Return Line Filter performs fine filtration for return oil in hydraulic systems. It removes metal wear particles from hydraulic components, rubber debris from seals and other contaminants, maintaining clean hydraulic oil inside the oil tank. The filter supports two installation methods: direct mounting on the oil tank cover or pipeline connection. Its glass fiber filter element delivers reliable filtration performance complying with international ISO standards.

2. Main Features

High filtration precision, large oil flow capacity

Low initial pressure loss, high dirt holding capacity

Glass fiber filter media; absolute filtration rating

Filtration ratio β3,5,10,20＞100, filtration efficiency ≥99%

Dual installation option: tank top mounting or pipe installation

Effectively protect hydraulic pumps, valves and actuators from abrasive wear

3. Typical Application Scenarios

Suitable for hydraulic systems of injection molding machinery, engineering machinery, metallurgical equipment, machine tools, agricultural machinery, hydraulic stations and other industrial hydraulic equipment.
