introduction

The TF series external self-sealing oil suction filter, also known as a Tank Mounted Suction Filter, is a filter installed at the suction port of an oil pump. Its primary function is to protect the oil pump and other hydraulic components by preventing the intake of contaminated impurities, thereby effectively controlling hydraulic system contamination and enhancing the cleanliness of the hydraulic system. This filter can be directly mounted on the side, top, or bottom of the oil tank, with its suction barrel immersed below the fluid level inside the tank while the filter head remains exposed outside the tank.
Product Features
- Convenient Installation and Connection: The TF series external self-sealing oil suction filter boasts an innovative design that simplifies installation, reduces system piping complexity, and lowers installation difficulty.
- Self-Sealing Valve Design: Equipped with a self-sealing valve, this filter ensures that oil within the tank does not leak out during filter element replacement, cleaning, or system maintenance, facilitating maintenance operations while avoiding oil waste and environmental pollution.
- Filter Element Contamination Indicator and Bypass Valve: Featuring a filter element contamination indicator and a bypass valve, it promptly signals when the filter element is clogged and automatically opens the bypass valve to prevent the oil pump from running dry and damaging, enhancing the reliability and safety of the hydraulic system.
- High Oil Flow Capacity and Low Resistance: The TF series external self-sealing oil suction filter boasts a large oil flow capacity and low resistance, contributing to the smooth operation of the hydraulic system.
- Easy Filter Element Cleaning or Replacement: The self-sealing valve design eliminates the need to drain the oil tank during filter element cleaning or replacement, significantly simplifying the process.
application area
The TF series external self-sealing oil suction filter finds extensive application in various industrial fields requiring hydraulic systems, including but not limited to heavy machinery, mining machinery, and metallurgical machinery. In these domains, the cleanliness and stability of the hydraulic system are crucial to equipment operation. The TF series external self-sealing oil suction filter, with its superior performance and features, provides robust support for the stable operation of hydraulic systems.
Customized filters of different specifications and models are available upon user's request.
