Introduction of WU/XU Series Oil Suction Filter:
This filter is a coarse filter and is generally installed at the oil suction port of the oil pump to protect the oil pump from inhaling large mechanical contamination impurities. The filter has a compact structure, simple installation, large oil passing capacity, and small resistance.
It is equipped with two installation forms, namely, pipe type, flange type connection, split net type, and line gap type.
Model and Technical Parameters of WU/XU Series Oil Suction Filter:
|
Filter model |
Dia (mm) |
Flow rate (L/min) |
Original pressure loss (MPa) |
Filtr. (μm) |
By-pass valve setting (MPa) |
connection method |
|
WU/XU-16X*-J |
12 |
16 |
≤0.01 |
80 100 180 for WU only |
x |
Tube type |
|
WU/XU-25X*-J |
15 |
25 |
0.02 |
|||
|
WU/XU-40X*-J |
20 |
40 |
||||
|
WU/XU-63X*-J |
25 |
63 |
||||
|
WU/XU-100X*-J |
32 |
100 |
||||
|
WU/XU-160X*-J |
40 |
160 |
||||
|
WU-225X*G-J |
50 |
225 |
Flange |
|||
|
WU/XU-250X*F-J |
50 |
250 |
||||
|
WU/XU-400X*F-J |
65 |
400 |
||||
|
WU/XU-630X*F-J |
80 |
630 |
||||
|
WU-800X*G-J |
63 |
800 |
Tube type |
|||
|
WU-1000X*G-J |
76 |
1000 |
||||
|
Note: According to user requirements, different specifications and models of filters can be customized. |
||||||
Hydraulic oil suction filter housing is a device used to filter out solid impurities in hydraulic systems.
The quality of hydraulic oil has a great impact on the working performance of hydraulic systems, and many faults are rooted in it. To prevent oil pollution, installing hydraulic oil filters in appropriate places can intercept pollutants in the oil, keep the oil clean, and ensure the normal operation of the oil system.
