Liquid tank type high-efficiency filter
Details
Product Features
Special aluminum profile outer frame, baffle-free structure
Easy installation and excellent sealing performance
Available in two designs: side liquid seal and top liquid seal
Recommended maximum resistance: 600 Pa
material quality
Frame: Aluminum alloy profile
Protective mesh: Painted mesh
Separator: Hot-melt adhesive
Sealant: Polyurethane
Sealing material: Special sealant for liquid tank filters
Filter media: Ultra-fine glass fiber filter paper, nano-fiber membrane filter material
aPPLICATION
Tailored for critical environments requiring airtight filtration and ultra-clean air, with core applications including:
High-end Cleanrooms (pharmaceutical sterile production, semiconductor wafer fabrication, lab research)
Biotech & Medical Facilities (aseptic filling lines, hospital operating rooms, ICU isolation wards)
Precision Manufacturing (aerospace component assembly, optical instrument production, electronics cleanrooms)
Food & Beverage Processing (aseptic packaging workshops, high-purity ingredient production)
Industrial High-Purity Systems (ultra-pure water treatment, chemical reagent production, paint-free spraying workshops)
specifications
| 型号 (model) | 规格尺寸 宽 × 高 × 深 (mm) (Size W×H×D (mm)) | 额定风量下的效率 % 0.3µm (Efficiency % at rated air volume 0.3µm) | 过滤面积 m² (Filter area m²) | 额定风量 / 初阻力 m³/Pa (Rated air volume/initial resistance m³/Pa) |
|---|---|---|---|---|
| GW-45-3390 | 305×305×90 | 99.995% | 3.20 | 250/220 |
| GW-45-6690 | 610×610×90 | 99.995% | 12.76 | 1000/220 |
| GW-45-9690 | 915×610×90 | 99.995% | 19.14 | 1500/220 |
