Precision Direct Back Hydraulic Return Line Oil Filter
Products Description
Key Features:
Ultra-High Efficiency (≥99.99% Counting Method)
It achieves a filtration efficiency of ≥99.99% for 0.3μm particles (counting method), meeting the strict air purity requirements of clean workshops in pharmaceutical, electronic, and precision manufacturing industries.
Partitioned Structure
This design ensures uniform airflow and maximizes the utilization of filter media, resulting in a large dust capacity (up to 1800g depending on the model) and an extended service life.
Low Resistance & Uniform Wind Speed
Engineered with an initial resistance of ≤220Pa and excellent wind speed uniformity, it reduces the energy consumption of HVAC systems while maintaining stable purification performance.
Customizable Specifications
It is available in various sizes (e.g., 320×320×220mm, 820×600×150mm, etc.) and configurations to suit different cleanroom layouts and local purification equipment.
Application Scenarios
Clean workshops in pharmaceutical, electronic, and semiconductor manufacturing.
Local purification equipment such as laminar flow hoods, FFUs (Fan Filter Units), and clean benches.
High-purity air supply systems in laboratories and precision instrument manufacturing facilities.
Model, Size and Technical Parameters
| 过滤器型号 | 外形尺寸 (mm) | 额定风量 (m³/h) | 初阻力 (Pa) | 效率 (%)(计数法 @0.3μm) | 容尘量 (g) |
|---|---|---|---|---|---|
| HGB-4A | 320×320×220 | 400 | ≤220 | ≥99.99 | 350 |
| HGB-5A | 350×350×220 | 500 | ≤220 | ≥99.99 | 400 |
| HGB-10A | 610×610×150 | 1000 | ≤220 | ≥99.99 | 600 |
| HGB-10A | 484×484×220 | 1000 | ≤220 | ≥99.99 | 600 |
| HGB-13A | 820×600×150 | 1300 | ≤220 | ≥99.99 | 750 |
| HGB-15A | 726×484×220 | 1300 | ≤220 | ≥99.99 | 750 |
| HGB-15A | 915×610×150 | 1500 | ≤220 | ≥99.99 | 800 |
| HGB-15A | 630×630×220 | 1500 | ≤220 | ≥99.99 | 900 |
| HGB-20A | 968×484×220 | 1500 | ≤220 | ≥99.99 | 1200 |
| HGB-20A | 1220×610×150 | 2000 | ≤220 | ≥99.99 | 1400 |
| HGB-23A | 945×630×220 | 2300 | ≤220 | ≥99.99 | 1200 |
| HGB-30A | 1260×630×220 | 3000 | ≤220 | ≥99.99 | 1800 |
Note: Different specifications and models can be customized according to user requirements.
